GHL Series High Speed Wet Mixer and Granulator

GHL Series High Speed Wet Mixer and Granulator

In the cylinder (conical) container, powder materials and binder will be mixed into moist soft materials by the mixed paddles at the bottom. Then they will be cutted into uniform wet-particles by the side high-speed smashed paddles

Product Description
Specification Parameter
Product Application
Product Feature
More Details

Product Description

Specification Parameter

Model	Container Volume	Working Volume	Mixing Power	Wet Mill Power	Compress Air Cons	Overall Dimension	Weight
Model	L	L	kw	kw	m3/MIN	W×H×D(mm)	kg
GHL-50	50	20-40	5.5	0.75	0.2	2000×1800×700	800
GHL-100	100	30-80	7.5	1.1	0.2	2700×3100×2200	1100
GHL-200	200	80-160	18.5	3	0.2	3000×3500×2300	2500
GHL-400	400	160-320	30	3	0.2	3300×4300×2700	3000
GHL-500	500	200-400	37	4	0.3	3400×4400×2900	4100
GHL-800	800	320-640	55	5.5	0.3	3500×5500×2700	5700

Product Application

The granulator of wet particles of powder injection binder is in the fields of pharmacy, food, chemical industry, etc.

Product Feature

1

It is the structure of horizontal cylinder (cone).
2

Full sealed driving shaft, to use water when cleaning.
3

Fluidization granulation, the finished granules are similar to roundness with good liquidity.
4

Compared with traditional process, it can reduce 25% binder and the dry time can be shortened.
5

Each batch of materials will be dry-mixed for 2 minutes and be granulated for 1-4 minutes. Compared with traditional process, it has improved by 4-5 times.
6

All the processes of dry-mixing & wet-mixing & granulating are finished in a closed vessel. So that it has reduced the process and also compiles with GMP standard.
7

Whole operation has the strict safety precautions.
