LTEC - series Electronic Counting Machine

LTEC - series Electronic Counting Machine

LTEC-Series Automatic Electronic Counting Machine is special for counting tablets, soft gelatin, hard capsule and chewing gums, etc.

Product Description
Specification Parameter
Product Application
Product Feature
More Details

Product Description

LTEC-Series Automatic Electronic Counting Machine is special for counting tablets, soft gelatin, hard capsule and chewing gums, etc.

This machine adopts multi sets imported counting sensor for counting with multi guiding way and two head.

The advantage of the machine is no need change mould when you change the counting object, only adjusting the counting table height by easy adjust wheel. The machine comes with touch screen operation and PLC Control for convenient running.

Specification Parameter

Model Name	LTEC-8	LTEC-16	LTEC-24	LTEC-32
Hopper Volume	20L	40L	45L	60L
Capacity	10-20bottles (80-100 pcs/bottle)/min	60-70bottles(80-100 pcs/bottle)/min 80-100 bottles(30-40 pcs/bottle)/min	80 bottles(50 pcs/bottle)/min	120bottles(50 pcs/bottle)/min
Compressed air	0.5Mpa	0.5Mpa	0.5Mpa	0.5Mpa
Machine Weight	120kg	500kg	500kg	800kg
Machine Size (mm)	660×1280×780	600 × 2400 × 1670	2000 × 1400 × 1680	2200 × 1400 × 1680

Product Application

LTEC-Series Automatic Electronic Counting Machine is special for counting tablets, soft gelatin, hard capsule and chewing gums, etc.

Product Feature

1

Compatibility, high accuracy, wide application and use of the Company's original anti-dust photoelectric detection of high technology, can count Tablets (including special-shaped tablets), capsules, soft capsules (transparent, opaque), pill count to bottling;
2

Vibratory cutting drugs do not damage;
3

A high degree of intelligence, with no bottle is not the number of self-fault detection alarm and many other control functions;
4

Compact structure, stability and durability, and no regular replacement parts, small footprint, the use of low-cost;
5

To facilitate the replacement of species, can automatically take-off and landing, demolition cleared without any tools, convenient and quick;
6

Chinese dialogue control panel, can store 10 ~ 20 group of species parameters, adjusted to facilitate the use of special;
7

Fully automatic operation, with the Upper and Lower Union Road, intelligent control of processes, coordination, and no special operation, labor-saving devices.
8

Low prices, especially for small-volume, variety and more manufacturers use.
9

Control chip imported to the United States, photoelectric sensors for Taiwan's imports.
